How to Order Electrified Cylindrical Locks

How to Order Electrical Cylindrical Locks

Please get in contact with us (you can find our info HERE).

Electrified Cylindrical Lock Ordering Guide

When ordering a part, specify (in this order): Lock Model No, Electrified EU or EL, Lever/Knob Design, Voltage (12 or 24 VDC), Cylinder, Finish, Voltage (12 or 24 VDC), and the hand.

Example: C380 EL 70 IC6 630 24VDC RHR

Electrified Options Reference:

EL - Electrically Locked (Fail Safe)

  • Outside Trim Locked When Power Applied
  • Outside Trim Unlocked When Power Removed
  • Latch by Key Outside
  • Inside Always Free

EU - Electrically Unlocked (Fail Secure)

  • Outside Trim Unlocked When Power Applied
  • Outside Trim Locked When Power Removed
  • Latch by Key Outside
  • Inside Always Free

LBM - Latchbolt Monitoring

Sends signal when latchbolt is drawn into the lock body

REX - Request to Exit

Sends signal when lever is activated from egress side

Available Electrified Trims:

Electrified cylindrical locks are available with the following trim options:

Lever Designs

  • No. 60 Lever
  • No. 70 Lever
  • No. 71 Lever
  • No. 80 Lever
  • No. 81 Lever
  • No. 82 Lever
  • No. 83 Lever

Knob Designs

  • No. 01 Series Knob

Rose Options

  • Standard Rose
  • Large Rose

Note: All electrified trims are available in standard finishes. For non-standard finishes or configurations, please append 'NSO' to your order.
